high-end thick medical pcb
craft show
| layers | 26l |
| product mix | 4-step |
| board thickness | 3.30±0.33mm |
| material | r5775n |
| line width / space | 96/76um |
| laser hole size | 100um |
| surface treatment | enig |
craft show
| layers | 26l |
| product mix | 4-step |
| board thickness | 3.30±0.33mm |
| material | r5775n |
| line width / space | 96/76um |
| laser hole size | 100um |
| surface treatment | enig |
craft show
| layers | 6l |
| product mix | 2r 2f 2r（1 step hdi） |
| board thickness | 1.2±0.12mm |
| 60/76um | 60/76um |
| laser hole size | 100um |
| surface treatment | enepig |
craft show
| layers | 8l |
| product mix | 2r 4f 2r |
| board thickness | 1.03 ±10% |
| line width / space | 0.076 mm/ 0.1mm |
| minimum laser drilling aperture | 0.35mm |
| surface treatment | enig |
craft show
| layers | 10l |
| product mix | 4r 2f 4r，3-step hdi |
| board thickness | 1.0±10% |
| line width / space | 0.076mm/ 0.007mm |
| minimum laser drilling aperture | 0.1mm |
| surface treatment | sink gold |
craft show
| layers | 10l |
| product mix | 4r 2f 4r,3-step hdi |
| board thickness | 0.88 ±10% |
| line width / space | 0.076mm/ 0.07mm |
| minimum laser drilling aperture | 0.1mm |
| surface treatment | sink gold |
craft show
| layers | 6l |
| product mix | 2r 2f 2r,2 step hdi |
| board thickness | 0.7 ±0.1mm |
| line width / space | 0.076mm/ 0.083mm |
| surface treatment | enig |
craft show
| layers | 6l |
| product mix | 2r 2f 2r |
| board thickness | 0.70 ±0.08mm |
| line width / space | 0.15mm/ 0.15mm |
| surface treatment | enig |
craft show
| layers | 4l |
| 1r 2f 1r | 1r 2f 1r |
| board thickness | 0.8 ±0.08mm |
| line width / space | 0.076 mm/ 0.1mm |
| surface treatment | enig |
jiangmen f2 products mainly hdi and r-fpc, used in mobile phone, led and other fields
